Limanda
Product range
Order No.
27.03 03 00
27.03 03 01
27.03 03 17
27.03 02 00
27.03 02 01
Enclosure type
Limanda I
Limanda I EMC
Limanda I for OP17
Limanda II
Limanda II EMC
Dimensions, W x L x H (mm)
311 x 281 x 72
311 x 281 x 72
311 x 281 x 97
270 x 248 x 64
270 x 248 x 64
Weight (kg)
1.2
1.2
1.5
0.8
0.8
Accessories
Order No.
Limanda I Aluminium front panel, natural anodized finish
Dimensions 269 x 199 x 3 mm, max. connector area 257 x 182 mm
Limanda I EMC front plate
Limanda II Aluminium front plate, natural anodized finish
Limanda II EMC front plate
Limanda I intermediate frames
Limanda II intermediate frames
Limanda II mounting set for Siemens TP 170 / TP 070
Limanda I EMC intermediate frame
Limanda II EMC intermediate frame
Limanda I handle set without push button
Limanda holder
Limanda I carrying strap
Limanda I quiver
Limanda II table stand (set = 2 pcs.)
Limanda II quiver
Limanda I quiver with intermediate frame
Limanda II quiver with intermediate frame
Limanda I handle set with 3-stage step enabling switch (right-hand version)
Limanda I handle set with 3-stage step enabling switch (left-hand version)
Cable connection with bending protection M 16
Cable connection with bending protection M 20
Cable connection with bending protection M 25
Inclining adapter for mounting directly on wall or machine
Inclining adapter for mounting directly onto GT 48/2 tube
Inclining adapter for mounting directly onto GTK electronic tube
Inclining adapter for mounting directly onto GT 48/2 or GTK electronic
Inclining adapter for Limanda bracket on GT 48/2 tube
Inclining adapter for Limanda bracket on GTK electronic tube
Inclining adapter for Limanda bracket on wall or machine
Push button and switches see page 53 - 58
27.03 03 80
27.03 03 90
27.03 02 80
27.03 02 90
27.03 03 81
27.03 02 81
27.03 02 82
27.03 00 88
27.03 02 88
27.03 00 83
27.03 00 84
27.03 00 85
27.03 00 86
27.03 00 87
27.03 00 89
27.03 00 90
27.03 00 91
27.03 00 71
27.03 00 72
08.10 01 16
08.10 01 20
08.10 01 25
50.02 00 01
50.02 00 02
50.02 00 03
50.02 00 04
50.02 00 05
50.02 00 06
50.02 00 07
on request
Limanda enclosure systems enable installation of
many manual operation panels.
Limanda I for OP17 -
Supplied ready for installation of the Siemens
Limanda II
with fitted command unit
OP17 Operator Panel without additional fitting
materials.
48
